Jack A5 Computerised Single Needle Lockstitch Machine

Jack A5 direct drive computerised lock stitch

JACK A5E-B Lockstitch

A single-needle lockstitch machine with automatic functions, bottom feed, and an energy-saving motor built into the machine head (Direct Drive). Like previous A5 versions, the machine features an elongated body – the distance from the needle to the body is 30.5cm.

Key Features and Specifications:

Semi-Dry System: A small, sealed oil tank replaces the traditional oil pan, preventing dust and oil stains.
  • Performance: Speeds up to 5000 stitches/min, with a maximum stitch length of 5mm.
  • Automatic Functions: Includes electronic thread tension control, auto thread trimmer, automatic back tacking, and automatic presser foot lifter.
  • User Interface: Features a simple, digital voice-assisted control panel and a USB port for charging devices.
  • Design: Features a shorter remaining thread length ,preventing bird's nests, and a direct-drive motor for energy efficiency.
  •
  • A5E Upgrades:
The updated Jack A5E / A5E-B (or "AMH") series offers an expanded, longer arm space (30.5 cm), higher torque for thick materials, an AI chip for material detection, and more intuitive operation buttons.
The Jack A5 is ideal for tailoring, alterations, and garment production where clean, high-quality, efficient stitching is required.

Technical Specifications


Model

Jack A5-D

Application

Light to Medium Weight

Needle

1738 (DBx1)

Max Sewing Speed

5,000 sti/min

Max Stitch Length

5mm (7mm H model)

Feed Dog Height

0.8mm

Presser Foot Height

By Hand: 5mm
Automatic: 9mm
Knee: 13mm

Voltage

220V

Working Area

305 x130mm

Dimensions

690x295x550mm

Weight

40 / 46kg

£799.00 inc VAT
